Parrameters | Unit | 1x1 / 2x2 | |
| Dimension | mm | 1x1 | (L)18.0×(W)7.3×(H)6 ±0.2 |
| 2x2 | (L)38.0×(W)7.3×(H)6 ±0.2 | ||
| Insertion Loss | dB | 1x1 | 0.8 |
| 2x2 | 1.2 | ||
| Wavelength Range | nm | 1520 ~ 1580 | |
| Test Wavelength | nm | 1550 | |
| Return Loss | dB | ≥ 50 | |
| Crosstalk | dB | ≥ 20 | |
| PDL | dB | ≤0.20 | |
| Repeatability | dB | ≤±0.01 | |
| Drive Voltage | V | 2.5±10% | |
| Drive Current | mA | 110~190 | |
| Durability | Cycles | ≥ 30 Billions | |
| Switch Type | NA | Latching | |
| Switching Time | us | ≤100（typ：50） | |
| Pulse Duration | us | 200~500 | |
| Relative Humidity | % | 5 ~ 95 | |
| Maximum Optical Power | mW | ≤ 500 | |
| Operating Temperature | ℃ | -5 ~ +70 | |
| Storage Temperature | ℃ | -40~+85 | |
| A: Switch Type | B: Fiber Type | C: Voltage | D: Wavelength | E:Tube Type | F: Fiber Length | G：Connector |
1x1B：Bidirectional 1x1U：Unidirectional 2x2B：Bidirectional 2x2U：Unidirectional | SM：SM，9/125 X：Others | 2.5：2.5V | 1550：1550nm X：Others | 25：250um 90：900um X：Others | 05：0.5m±5cm 10：1.0m±5cm 15：1.5m±5cm X：Others | OO：None FP:：FC/PC FA：FC/APC SP：SC/PC SA：SC/APC LP：LC/PC LA：LC/APC X：Others |
High switching speed
Better durability
High reliability
Low voltage drive
Fail-safe latching
◆Optical channel blocking
◆Configurable Add/Drop
◆System monitoring,Test&measurement
◆Fiber-optics sensing system
