Parrameters | Unit | SUN-FSW-8+1 |
| Dimension | mm | (L)51.8×(W)46.8×(H)9.7 ±0.2 |
| Wavelength Range | nm | 1260 ~ 1650 |
| Test Wavelength | nm | 1310 / 1550 |
| Insertion Loss1，2 | dB | ≤ 1.0 |
| Return Loss1，2 | dB | ≥ 50 |
| Crosstalk1 | dB | ≥ 55 |
| PDL | dB | ≤0.1 |
| WDL | dB | ≤ 0.30 |
| Repeatability | dB | ≤±0.02 |
| Operating Voltage | V | 3.0 or 5.0 |
| Switching Time | ms | ≤8 |
| Durability | Cycles | ≥ 10 Millions |
| Switch Type | NA | Latching |
| Operating Current | mA | ≤ 200 |
| Optical Power | mW | ≤ 500 |
| Operating Temperature | ℃ | -5 ~ +70 |
| Storage Temperature | ℃ | -40~+85 |
| Relative Humidity | % | 5 ~ 95 |
| A: Fiber Type | B: Operating Voltage | C: Switch Type | D: Test Wavelength | E:Tube Type | F: Fiber Length | G：Connector |
SM：SM, 9/125 X：Others | 3：3V 5：5V | L：Latching N：Non-latching | 1310：1310nm 1550：1550nm 1310/1550：1310/1550nm X：Others | 250：250um 900：900um X：Others | 05: 0.5m±5cm 10: 1.0m±5cm X: Others | OO：None FP：FC/PC FA：FC/APC SP：SC/PC SA：SC/APC LP：LC/PC LA：LC/APC X：Others |
Low Insertion Loss
Wide Wavelength Range
Low Crosstalk
High Stability, High Reliability
Epoxy-free on Optical Path
Latching and Non-latching
◆R&D in Laboratory
◆OADM
◆MAN(Metropolitan Area Network)
◆Network Security and Monitoring
